Features
Ultra miniature SMD tuning fork crystal resonator
A ceramic package with metal lid providing high precision and reliability.
Metal lid connected to GND terminal to reduce EMI
Suitable for mobile communications and consumer devices.
Applications
Mobile communications and consumer devices, etc.
Smart card and Wearable devices
Type :
AS1Model :
PSX1610Package size :
1.6*1.0*0.5 mmFrequency :
32.768KHZ1610 size 32.768kHz Watch Crystal
SMD Tuning Fork Crystal PSX1610 is an ultra-miniature surface mount tuning fork crystal oscillator in a ceramic package with a metal cover, providing high accuracy and reliability. The metal cover is connected to the ground terminal to reduce electromagnetic interference. Suitable for mobile communications and consumer devices such as smart cards and wearable devices. The product has a highly competitive price, measures 1.6 x 1.0 x 0.5 mm, has excellent reliability and ultra-small package. Supports surface mount technology and infrared reflow soldering process. Highly competitive price for smallest watch crystal with 1.6 x 1.0 x 0.5mm. PSX1610 also with excellent reliability performance and ultra miniature package. And is available in a choice of circuit conditions at 32.768kHz which suitable for surface mount technology and IR reflow process.
1. ELECTRICAL SPECIFICATIONS
| Parameter | Symb | Electrical Specification | Condition | |||
| Min | Type | Max | Units | |||
| Frequency Range | FO | 32.768 | KHz | |||
| Frequency Tolerance | △f/fo | ±5 | ±20 | ±50 | PPM | REF TO 25℃ |
| Temperature Coefficient | K | （-0.03±0.01）*10-6 | ppm/(℃)2 | |||
| Turnover Temperature | TTO | 20 | 25 | 30 | ℃ | |
| Operating Temperature Range | TOP | -20~70 -40~85 |
℃ | |||
| Storage Temperature Range | TST | -55 | 125 | ℃ | ||
| Quality Factor | Q | 10,000 | Typ | |||
| Series Resistance | R1 | 90 | KΩ | REF TO 25℃ | ||
| Shunt Capacitance | CO | 1.3 | Typ | 7PF or less | ||
| Load Capacitance | CL | 6 | 12.5 | PF | ||
| Insulator Resistance | IR | 500 | MΩ | DC100V±15V | ||
| Drive Level | DL | 0.1 | 0.5 | цW | ||
| Capacitance ratio | R | 450 | TYP | |||
| Aging Rate | △/f | ±5 | ±5 | PPM | at 25℃±3℃ | |
| Moist are Sensitivity Level | MSL | 1 | J-STD-033 | |||
| Package type | 1.6*1.0*0.5 | |||||
2. Dimension (Unit: mm)
